Brodie Elan 2.0

Brodie Elan 2.0
$2,199.00
Size: Select size
Please select options Unavailable
Order now and pick up in-store for free

Details

Is the updated Elan 2.0 an evolution or even a revolution of our adventure touring bike? We will let you decide! The Elan 2.0 is now more capable of your off road adventure. Versatility will always a big part of the Elan but now it has been improved for bigger load carrying and rougher terrain. The Elan 2.0 has updated geometry and now comes with Thru-Axles front and rear. We have moved the front/center more forward with an increase rake in the fork for more stability when fully loaded with all your gear.

Both the Elan 2.0 and Elan Vital 2.0 represent the modernization of the classic touring bike. They both share the same Geometry and CrMo Steel frame and able to accommodate a myriad of tires sizes to dial in the needs of your next adventure.

Shimano drivetrain with a GRX Adventure Crankset w 46/30T rings, paired with Shimano Tiagra 10 Speed shifters & 11-36T full range cassette. Shimano Mechanical Brakes that are easy to adjust, offer great modulation and have incredible stopping power.

The Elan is a terrific go anywhere touring or bike packing adventure bike.

Specs

Frame 4130 CroMo DB Steel, #allthemounts
Fork 4130 CroMo Steel, fender + 3 eyelets / Leg
Headset FSA Orbit-X, Angular contact Sealed Bearing
Rear Shock N/A
Rims WTB ST Light, 25mm inner width, TCS 2.0, Sleeved, 32 hole
Hubs F: Shimano Tiagra 470 12x100mm R: 12x142mm
Tires WTB Ranger Comp, Fast Rolling. 29x2.25
Crankset Shimano GRX-600
Chainwheel 46/30t
Chain KMC X10-1
Front Derailleur Shimano GRX 400
Rear Derailleur Shimano GRX 400 GS
Rear Cogs Shimano Tiagra 10spd 11-36 teeth
Shifters Shimano Tiagra
Handlebars Brodie Alloy DB Flared bar S-400, M-420, L/XL-440mm
Tape/Grips Perforated road tape
Stem Brodie 3D Forged Aluminium, S - 70mm, M - 90mm, L - 100mm, XL - 110mm
Brake Levers Shimano Tiagra
Brakes Shimano mechanical disc, BR-RS305
Pedals N/A
Saddle WTB Koda Race, CroMp rails, Micro-fibre
Seat Post Brodie Alloy 27.2mm
Accessories & Extras F+R Thru Axles
Color(s) Burnt Red
Sizes S-46cm, M-50cm, L-54cm, XL-58cm

* Subject to change without notice.

Part Numbers

Option MPN Store SKU
S-46
M-50 1988 338 050M 210000016617
L-54
XL-58
