Brodie Elan Vital 2.0

Brodie Elan Vital 2.0
$2,799.00
Size: Select size
Please select options Unavailable
Order now and pick up in-store for free

Details

The evolution, maybe even a revolution of our adventure touring bike now makes it more capable of your off road adventure. Versatility is still a big part of the Elan Vital but now it has been improved for bigger load carrying and rougher terrain. The Elan Vital 2.0 has updated geometry and now comes with Thru-Axles front and rear. We have moved the front/center more forward with an increase rake in the fork for more stability when fully loaded with all your gear.

The Elan Vital 2.0 comes with 29 x 2.25” WTB RANGER COMP Fast rolling tires.If you need to go even bigger the frame will accommodate up to a 29 x 2.4” Tire !

Plenty of grip off the pavement while still plenty fast on the pavement. We added a bit more room for frame bags and storage and left plenty of room for full size panniers out back. The New CroMo Steel Frame and Fork both have triple water bottle mounts for Cargo Cages.

The Shimano drivetrain with a GRX Adventure Crankset w 46/30T rings & 11-34T full range cassette and Shimano Hydraulic GRX Brakes that are easy to modulate and have incredible stopping power.

The Elan Vital is the perfect anywhere touring or bike packing any adventure bike.

Specs

Frame 4131 CroMo DB Steel, #allthemounts
Fork 4131 CroMo Steel, fender + 3 eyelets / Leg
Headset FSA Orbit-X, Angular contact Sealed Bearing
Rear Shock N/A
Rims WTB ST Light, 25mm inner width, TCS 2.0, Sleeved, 32 hole
Hubs F: Shimano Tiagra 470 12x100mm R: 12x142mm
Tires WTB Ranger Comp, Fast Rolling. 29x2.25
Crankset Shimano GRX-600
Chainwheel 46/30t
Chain KMC X11-1
Front Derailleur Shimano GRX 810
Rear Derailleur Shimano GRX 810 11spd
Rear Cogs Shimano 105 11spd 11-34t
Shifters Shimano GRX 810
Handlebars Ritchey Coralitas. 52mm reach 24° Flare, 67.5mm Drop
Tape/Grips Perforated road tape
Stem Brodie 3D Forged Aluminium, S - 70mm, M - 90mm, L - 100mm, XL - 110mm
Brake Levers Shimano GRX Hydraulic
Brakes Shimano GRX Hydraulic
Pedals N/A
Saddle WTB Koda Race, CroMp rails, Micro-fibre
Seat Post Brodie Alloy 27.2mm
Accessories & Extras F+R Thru Axles
Color(s) Desert Sand
Sizes S-46cm, M-50cm, L-54cm, XL-58cm

* Subject to change without notice.

Part Numbers

Option MPN Store SKU
S-46 1988 340 046S 210000016614
M-50 1988 340 050M 210000016615
L-54 1988 340 054L 210000016616
