SLAY TECHNICAL TRAILS ON THE E-BIKE THAT NEVER HOLDS BACK.
KEY PERFORMANCE FACTORS
With up to 180 km* range of the ultra-reliable EnergyPak Smart 625Wh battery and the SyncDrive Pro motor and the versatility of flip chip adjustable frame geometry, the Intrigue X E+ allows you to explore more than ever before.
*Actual range depends on several factors including weight, elevation, terrain, and acceleration.
The easy-to-access EnergyPak Smart is beautifully integrated into a lightweight and durable ALUXX SL aluminum frame designed and tuned for women.
Ample Maestro suspension and Smart Assist Technology with 6-sensor measurements smooth out bumps for a natural ride feel.
27.5-INCH (XS)/ 29-INCH (S-L) WHEELS
XS frames come with 27.5-inch wheels, S, M, and L frames come with 29-inch wheels to provide the best fit for riders
ADVANCED FORGED COMPOSITE TECHNOLOGY
A state-of-the-art high-pressure molding process is used to produce complex-shaped carbon fiber components that are lighter, stiffer and stronger than similar components made from aluminum. This technology is used in critical performance parts such as Maestro Suspension rocker link.
ALUXX SL-GRADE ALUMINUM FRAME
The state-of-the-art aluminum material delivers best-in-class strength-to-weight ratios. These framesets also feature unique welding technologies for a high-performance ride.
MAESTRO SUSPENSION SYSTEM
140mm of rear travel, four strategically positioned pivot points and two linkages work together to create a single floating pivot for the most active and efficient suspension system on the trail.
An integrated flip chip lets you change the headtube and seattube angles, along with the bottom bracket height, to fine-tune the handling. You can choose the low position for faster, open terrain or high for slower, tighter single track.
SYNCDRIVE PRO MOTOR
The lightweight and powerful SyncDrive Pro motor comes in a compact package, delivering a performance-oriented ride. Whether you want to find fitness inspiration, fly up technical trails, or conquer an E-bike cross country race, the SyncDrive Pro delivers, offering a powerful 80 Nm force with a max of 170 rpm.
With Smart Assist you can enjoy seamless acceleration and power boost. The Smart Assist Technology replicates a natural riding style, using the six sensors to add assistance exactly when needed.
RideControl Ergo takes your E-bike riding experience to new levels with smart integration buttons for clean and simple display-free handlebar controls. Ergonomic and accessible while riding, easy-to-push buttons let you select your power mode and activate Walk Assist.
The EnergyPak Smart is your secret weapon for maximum capacity on longer rides. The EnergyPak Smart is well-designed and smoothly incorporated into the bottom of the downtube to create a streamlined look and a compact profile that closely matches the design of standard bikes.
COMPATIBLE WITH 2.6-INCH TIRES
The Intrigue X E+ has the frame clearance to run up to 2.6-inch wide tires for increased stability.
BOOST HUB SPACING
Wider hub spacing (15x110mm front, 12X148mm rear) results in stiffer wheels for added control. This allows more tire clearance and an improved chainline for optimal drivetrain performance.
|A||SEAT TUBE LENGTH (mm)||385||405||435|
|B||SEAT TUBE ANGLE||74.5° | 75.2°||76.0° | 76.7°||76.0° | 76.7°|
|C||TOP TUBE LENGTH (mm)||565 | 565||568 | 568||585 | 585|
|D||HEAD TUBE LENGTH (mm)||95||95||100|
|E||HEAD TUBE ANGLE||65.0° | 65.7°||65.8° | 66.5°||65.8° | 66.5°|
|F||FORK RAKE (mm)||44||44||44|
|G||TRAIL (mm)||129.6 | 124.2||123.4 | 118.1||123.4 | 118.1|
|H||WHEELBASE (mm)||1190 | 1193||1195 | 1198||1213 | 1216|
|I||CHAIN STAY LENGTH (mm)||472 | 472||472 | 472||472 | 472|
|J||BOTTOM BRACKET DROP (mm)||11 | 1||30 | 20||30 | 20|
|K||STACK (mm)||585 | 579||608 | 602||613 | 607|
|L||REACH (mm)||403 | 412||416 | 426||432 | 442|
|M||STAND OVER HEIGHT (mm)||729 | 738||751 | 760||766 | 775|
|N||HANDLEBAR WIDTH (mm)||750||750||780|
|O||STEM LENGTH (mm)||40||40||50|
|P||CRANK LENGTH (mm)||160||165||165|
|Frame||ALUXX SL-grade Aluminum, Advanced Forged Composite Upper Rocker, 140mm Maestro Suspension System, 'Boost' 148x12QR, ISS|
|Fork||Rock Shox 35 Gold RL DebonAir, 150mm travel, 44mm offset, MotionControltm rebound and lockout control, 15x110 Boost, Maxle Stealth, e-MTB optimized|
|Rims||Giant AM 29 / 27.5+, Tubeless ready, 30mm inner width|
|Hubs||Giant eTracker Boost, Sealed cartridge bearing, 6-bolt, , [F] 110x15 [R] 148x12mm Thru-axle|
|Spokes||Sapim E-Lite [r] Race [f]|
|Tires||Maxxis Assegai 29x2.6" foldable, Tubeless, EXO [F]Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+ [R] (XS: 27.5+ / S-L: 29)|
|Crankset||Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (XS/S:160, M:165, L:170)|
|Front Derailleur||MRP 1X CS custom|
|Rear Derailleur||Shimano Deore 12-speed|
|Chain||KMC e.12 Turbo, EcoProteq, e-bike optimized|
|Brakes||Shimano BR-MT200, hydraulic, Shimano RT-26 rotors [F]203mm, [R]203mm **some bikes may be substituted: Tektro HD-M745 Orion, 4-piston hydraulic, [F] 203mm, [R] 203mm|
|Brake Levers||Shimano BL-MT201 **some bikes may be substituted: Tektro HD-M745 Orion|
|Stem||Giant Contact SL 35|
|Seatpost||Giant Contact Switch, dropper, 30,9mm (XS-S: 100, M:125, L:150)|
|Saddle||Liv Sylvia E+|
|Motor||SyncDrive Pro,80Nm, powered by YAMAHA|
|Battery||EnergyPak Smart 625Wh EnergyPak Plus range extender compatible|
* Subject to change without notice.
|Supernova / X-Small / 27.5-inch||04712878800793||2203378103||210000013481|
|Supernova / Small / 29-inch||04712878800809||2203378104||210000011504|
|Supernova / Medium / 29-inch||04712878800816||2203378105||210000011132|
